Image Sensor

1/3" Sharp Color CCD

Signal System

NTSC

Effective Pixels

1020(H) x 508(V)

Horizontal Resolution

700 TV Lines

Minimum Illumination

0 LUX (IR on)

Scanning Area

4.9mm(H) x 3.7mm(V)

S/N Ratio

>48dB

Electronic Shutter

1/60 to 1/100,000 sec

Video Output

1.0Vp-p, 75ohms

Supply Voltage

DC 12V

Power Consumption

Min Req: 500mA / Recommended: 1A

Lens

2.8-12mm Vari-Focal

IR Wavelength

850nm

IR Lamps

36 leds

IR Distance

90FT.
